23216Integrated Radar Controllers
Integrated Radar Controllers
Integrated radar dual-color controller with automatic color-temperature switching, 7–8 m microwave sensing and up to 7A charging.
Product Features
- Integrated radar dual-color controller with automatic color-temperature switching
- 3.2V system, up to 7A charging current
- 7–8 m microwave sensing — full light on motion, dim when still
- Automatic light control and daytime charging
Technical Specifications
| Electrical | Electrical | ||||
|---|---|---|---|---|---|
| Max charging current | 7A | Standby consumption | |||
| Standby consumption | 300/500/600µA | ||||
| Input voltage | 2.5/3.2/4.2V | Operating current | |||
| Operating current | 1.5–16mA | ||||
| Max discharge current | 5A | ||||
| Sensing & Control | Sensing & Control | ||||
| Mounting height | 3/4/6 m | Sensing radius | |||
| Sensing radius | 7–8 m (varies with height) | ||||
| Mechanical & Others | Mechanical & Others | ||||
| Dimensions | 68.8×23×1.2 mm | ||||
